LIMAX22 Linear Encoder
Magnetic Linear Measuring System
The ELGO LIMAX22 is a high-precision magnetic linear measuring system for absolute and incremental position measurement. With a compact profile and sealed housing, the LIMAX22 is ideal for integration into machines where reliable linear positioning is essential.
Key Features
- Absolute and incremental measuring modes
- Magnetic sensing for wear-free operation
- Compact aluminium profile housing
- Measuring lengths up to several metres
- Resolution down to 1 µm
- IP65 protection rating
- SSI, BiSS, and analogue interfaces
Specifications
| Output | Stroke Length | Resolution |
|---|---|---|
| SSI / BiSS | Up to 4000 mm | 1 µm |
| Analogue | Up to 4000 mm | 1 µm |
