ATR444
PID Controller, 48x96mm (1/8 DIN)
The Pixsys ATR444 is a 1/8 DIN PID controller with a wide alphanumeric display carrying process and alarm variables alongside scrolling status messages and on-screen help. An eight-key keypad allows dedicated function keys to be assigned to repetitive operations. Two universal analog inputs support mathematical operations between processes, with open-close control for motorised valves, multiple alarm and diagnostic modes, and timer functions.
Key Features
48x96mm panel cutout, 1/8 DIN
Wide alphanumeric display with scrolling status messages and on-screen help
Eight-key keypad with assignable function keys
Two universal analog inputs with mathematical operations between processes
Open-close control for motorised valves
Multiple alarm and diagnostic modes
Timer functions
NFC/RFID configuration via the MyPixsys app
Pixsys ATR444 in Ireland
The ATR444 is the largest controller in the Pixsys Blue Line range, in a 48x96mm 1/8 DIN cutout. The wide alphanumeric display carries textual status and event messages rather than numeric codes, and the eight-key keypad allows function keys to be assigned to operations that would otherwise require menu navigation. Two universal analog inputs support mathematical operations between processes, with open-close motorised valve control and timer functions covering applications that a single-loop controller cannot.
The ATR444 is specified where the operator interacts with the controller regularly and display clarity or single-key operations matter, or where two processes require mathematical relationships rather than independent control. Typical applications include process plant with operator adjustment, kilns and heat treatment, and production equipment with timed sequences. Suitable for any application requiring panel-mounted PID control with a larger display, assignable function keys or motorised valve control.
Emolice is the only official Pixsys distributor in Ireland. Contact Emolice with your specification.
