G-Series
Industrial Position Sensors, Backward Compatible
The Temposonics G-Series GTE and GT2/GT3 redundant sensors provide linear position measurement for applications where redundancy is required for safety or availability. Each unit contains two or three independent measuring channels in a single housing. The GTE variant carries ATEX certification for hazardous areas. Standard GH and GP non-redundant variants have been replaced by the G-Series V.
Key Features
Rod version (GH) for cylinder integrated position measurement
Profile version (GP) for external motion axis measurement
Redundant rod version (GT2/3) with two or three independent measuring systems
Redundant embedded cylinder version (GTE) with ATEX certification
Outputs: Analog, Start/Stop, PWM
Reliable position measurement for safety and availability requirements
Legacy product. The Temposonics G-Series is being phased out in favour of the G-Series V. Emolice can supply both and cross-reference any existing part number for you.
Upgrade your G-Series to the G-Series V
The G-Series V is the backward-compatible successor to the G-Series, built on the proven G-Series mechanical platform with the upgraded electronics of the R-Series V. In most analog, PWM and Start/Stop installations it is a direct replacement.
Legacy
G-Series
GH / GP / GT
Current
G-Series V
GH5 / GP5
What you gain by moving to the G-Series V
- Backward compatible mounting, stroke and magnet with G-Series
- Improved vibration and shock resistance
- On-site reconfiguration via TempoLink Smart Assistant
- Analog (0–10 V, 4–20 mA), PWM and Start/Stop outputs
- Long-term availability, the G-Series is being phased out
Temposonics G-Series in Ireland
Analog output only. Measuring range 50mm to 3,500mm.
The G-Series redundant range is specified where a single sensor failure on a critical axis must not interrupt position measurement. Typical applications include safety-critical linear axes on industrial presses, die casting machines and process plant where dual or triple redundant position feedback is a machine certification requirement. The GTE is specified for the same applications in ATEX Zone 1 or Zone 2 hazardous areas.
Emolice is the only authorised Temposonics distributor in Ireland.
Specifications
| Output | Stroke Length | Resolution |
|---|---|---|
| Analog | 50–3500 mm | < 2 µm |
Applications
Safety-critical linear axes where a single sensor failure must not interrupt position measurement
Industrial presses and die casting machines with dual or triple redundant feedback
Process plant where redundant position feedback is a machine certification requirement
ATEX Zone 1 and Zone 2 hazardous area installations (GTE version)
Replacement of installed GT2, GT3 or GTE sensors
Selection Guidance
The G-Series covers the redundant range only: GT2 with two independent measuring channels, GT3 with three, and GTE with ATEX certification for hazardous areas. Output is analog, with stroke lengths from 50 mm to 3,500 mm. The non-redundant GH and GP variants have been replaced by the G-Series V.
Redundant G-Series sensors use the GT2, GT3 or GTE prefix. Contact Emolice for selection guidance. Use the Part Number Decoder →
Official Temposonics Distributor
Emolice is the authorised Temposonics distributor in Ireland, providing genuine products, factory-trained support, and full warranty coverage.
Ireland-Based Support
Technical support and application guidance. Learn more about Temposonics in Ireland
Need a Quote or Technical Support?
Emolice is the only authorised Temposonics distributor in Ireland. Contact Emolice for pricing and application guidance.
Ireland support: technical support and application guidance. Call +353 1 568 6556
Frequently Asked Questions
Which G-Series variants remain available?
The redundant range: GT2, GT3 and GTE. The non-redundant GH and GP variants have been replaced by the G-Series V.
What is the difference between GT2, GT3 and GTE?
GT2 carries two independent measuring channels in one housing, GT3 carries three, and the GTE is an embedded cylinder version with ATEX certification.
What stroke lengths and output does the redundant range cover?
Analog output with stroke lengths from 50 mm to 3,500 mm.
Can the GTE be used in a hazardous area?
Yes, the GTE carries ATEX certification for installation in Zone 1 and Zone 2 areas.
